Auger Drives

The AD Series of auger drives offers manufacturers multiple motor displacements for different GPM auger applications. Either bevel gearboxes or high torque planetary gearboxes are supplied depending on the required use. The AD Series can be provided with or without a cross port relief for shock load failure prevention. With multiple output shaft options available, the AD Series is highly configurable.

Categories: , Tag:

PHD Series

Model Gearbox Max Intermittent Torque (Nm) Standard Motor Flange Standard Input Spline Standard Ratio
PHD-50 PHD-50 751 SAE “A” 4-Bolt Magneto 13 Tooth 16/32 3.18:1

AD Series

Model Gearbox Max Intermittent Torque (Nm) Standard Motor Flange Standard Input Spline Standard Ratio
AD-02 SS-02 1,695 SAE “A” 4-Bolt Magneto 14 Tooth 12/24 3.6
AD-03 SS-06 3,390 SAE “A” 4-Bolt Magneto 14 Tooth 12/24 3.75
AD-05 SD-06 5,650 SAE “A” 4-Bolt Magneto 14 Tooth 12/24 14.06
AD-06 SS-06 4,067 SAE “A” 4-Bolt Magneto 14 Tooth 12/24 4.43
AD-12 SD-12 11,300 SAE “A” 4-Bolt Magneto 14 Tooth 12/24 19.67
AD-20-1 OPH-18 18,000 SAE “C” 2 Bolt 14 Tooth 12/24 67.9
AD-20-2 OPH-18 18,000 SAE “C” 2 Bolt 14 Tooth 12/24 16.6/67.9
