Planetary Wheel Drive

Categories: , Tags: , , ,

Description

WS Series

Model Max Intermittent Torque (Nm) Max Input Speed (RPM) Radial Load (KG) Single Reduction Hydraulic Flange Input
WS-02 1,700 4,000 3,200 x x
WS-06 2,900 3,500 4,600 x x
WS-12 6,800 3,500 7,300 x x

WD Series

Model Max Intermittent Torque (Nm) Max Input Speed (RPM) Radial Load (KG) Double Reduction Hydraulic Flange Input
WD-02 1,700 4,000 3,200 x x
WD-03 3,400 4,000 3,200 x x
WD-06 5,700 5,000 4,600 x x
WD-12 11,300 5,000 7,300 x x

VB Series

Model Max Intermittent Torque (Nm) Max Input Speed (RPM) Radial Load (KG) Double Reduction Triple Reduction Hydraulic Cartridge Input Electric Motor Input
VB-07 7,000 5,000 6,400 x x x
VB-09 9,000 5,000 x x x x
VB-11 11,000 5,000 7,300 x x x x
VB-13 13,000 5,000 8,200 x x x x
VB-18 18,000 5,000 8,200 x x x x

VE Series

Model Single Reduction Double Reduction Hydraulic Flange Input Hydraulic Cartridge Input
VE-01 x x x x

VA Series

Model Max Intermittent Torque (Nm) Max Input Speed (RPM) Radial Load (KG) Single Reduction Double Reduction Hydraulic Flange Input Electric Motor Input
VA-02 1,800 4,000 x x x x
VA-07 7,000 5,000 6,400 x x x
VA-09 9,000 5,000 x x x
